Upload attachment to SharePoint list item using Microsoft Flow

Microsoft Flow is one of the Microsoft offerings for automation. In this series will see how to upload a file to SharePoint ListItem using MSFlow

 Workflow for our scenario

Login to Microsoft Flow site and log in to create a new flow.

Add action and Type 'Data Operations' connector.

Then choose 'Data operations - Compose' action


Select 'Expression' tab and enter the following to create 'ListName' variable


Repeat this process for all other variables
  • ListName - SharePoint list name.
  • ItemID     - SPList item ID.
  • AttachmentContent - Actual attachment content.
  • FileName - Attchment name.

Expressions: we can read values from Query String will discuss how to pass them next article.

ListName:
trigger()['outputs']['queries']['listname']

ItemID:
trigger()['outputs']['queries']['itemid']

Attachment Content:
triggerMultipartBody(0)['$content']

fName: - FileName
replace(split(string(split(string(json(concat(triggerOutputs()['body']['$multipart'][0]['headers'],''))['Content-Disposition']),';')[2]),'=')[1],'"','')


 Flow will look like this after the above steps

Add 'SharePoint' connector then select 'SharePoint-GetAttachments'

Add ListName & ID from the dynamic variables


 Now 'Add a condition' action to check the count > 0

length(body('Get_attachments'))


 perform following

Delete attachment - action

Add attachment - action

 With this setup, we are good to upload any file to the dynamically configured list item. in next article will see How to upload file via MS Flow endpoint using Javascript and PowerApps integration to this MS Flow using Swagger a.k.a OpenApi. I recommend reading the PowerApps scratch development series, Azure Function integration with PowerApps and What is Microsoft Flow.

-Ratsub
